- Hign-concerned Chemical: None
- Processor Main Frequency: depend on the CPU
- Use: Commercial
- Memory Capacity: 32GB
- Hard Drive Capacity: ≥ 1.5TB
- Model Number: K4
- Processor Brand: Intel
- Processor Model: Intel Core
- Type: Mini Desktop
- Graphics Card Type: Integrated Card
- Brand Name: VENOEN
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- Type: MINI PC
- Case Material: Brushed Aluminum Alloy
- USB port: 2*USB2.0+4*USB3.0
- Display: HDMI+VGA
- LAN Port: 2*RJ45 intel i225-V
- COM Port: 6* DB9 pin COM RS232
- Operating System: Windows 10 Linux UbuntuKodi XBMC
- SSD: 1*MSATA+1*SATA3.0
- Chassis size: 240MM*150MM*57MM
Processors Performance
|
CPU |
Cores & Threads |
Frequency |
Cache |
TDP |
Graphics |
|
Core i5-8250U |
4 cores 8 threads |
2.6GHz |
6MB cache |
23-28W |
Intel® Iris® Graphics 550 |
|
Core i7-8550U |
4 cores 8 threads |
3.4GHz |
8MB cache |
15-25W |
Intel® HD Graphics 620 |
|
Core i5-4200U |
2 cores 4 threads |
4.0GHz |
3MB cache |
15-55W |
Intel® HD Graphics 4400 |
PC had best to use Samsung, SKhynix, Micron etc original brand accessories, We DO NOT compensate for buyer's own ram and hard drive.For bulk purchases please contact me directly
What In The Package
1x Mini PC;
1x AC adapter (we ship correct power plug base on buyer's address );
1x Power cord;
1x WiFi module and antennas ("NO SSD NO RAM" bundle package without WiFi module and antennas );
1x SATA Power cable & data cable;
1 x User manaul & warranty card.
Buyer's Guide
1) Buyer please select processor from " Bundle " option, and select memory capacity and hard drive capacity from " Color " option ; If you need other combination, please leave us message and we will offer quotatio.
2) Buyer select DHL/Fedex shipping method, should be sure your address is belong to normal delivery area, otherwise there will be extra cost for delivery, if your address is out of normal delivery area, our salesman will inform you asap; or we will ship out by other shipping method;
3) All items price NOT include destination custom taxes and VAT.
|
CPU |
i5-8250U (4 cores,8threads, base frequency:1.6GHz, max turbo frequency:3.4GHz, L3 cache: 6MB) |
|
CPU-TDP |
15W |
|
Complete power (maximum) |
48W(Core i5-8250U/i7-8550U) |
|
Photolithography |
14NM(Core i5-8250U/i7-8550U) |
|
Intel® AES-NI |
Support |
|
Memory slot |
2*DDR4 260pin SO-DIMM, maximum memory capacity 64G (32G *2) , (Core i5-8250U/i7-8550U) |
|
Sound card |
Realtek ALC 897 |
|
I/O interface |
|
|
USB |
2*USB2.0+4*USB3.0(Type-A) |
|
DC |
DC input port*1, suitable for 5.5*2.5MM DC port |
|
Audio |
3.5MM audio output*1 |
|
Lan |
2*RJ45 intel i225-V (2.5G Gigabit Ethernet)(Core i5-8250U/i7-8550U/i5-4200U) |
|
COM |
6* DB9 pin COM RS232 |
|
1Antenna |
2* Antenna interface, used to connect WIFI module external antenna |
|
Video port |
|
|
HDMI |
1* HDMI (1.4) 4096×2304@24Hz(Core i5-8250U/i7-8550U) |
|
VGA |
1*VGA 1920*1080@60HZ |
|
Graphics card model |
Intel® UHD Graphics 620(Core i5-8250U/i7-8550U) |
|
Storage |
|
|
MSATA |
1*MSATA (up to 1TB) |
|
SATA3.0 |
1*SATA3.0, used to install 2.5-inch HDD/SSD (up to 2TB) |
|
Common motherboard interface |
|
|
Expansion slot |
1*MPCIE Full height, used for installing WIFI module4G module |
|
SIM slot |
1*SIM card slot, suitable for standard SIM card (25*15*0.8mm) |
|
Other |
|
|
Power input |
12V 5A |
|
Other functions |
Automatic startup, scheduled startup, network wake-up, PXE (support UEFI and Legacy), RAID (RAID0/RAID1) |
|
Supported systems |
Win10Win11Linux |
|
Installation method |
Place on the desktop, fix on the wall, support VESA mount |
|
Working environment temperature |
-20°~60°' temperature 0-95% relative humidity, no condensation |
|
Motherboard size |
148MM*102MM |
|
Chassis size |
240MM*150MM*57MM |
|
Host net weight |
1.4KG |
|
Complete weight (including all accessories) |
2.KG |
|
Chassis material |
Aluminum |
SIM & 3G/ 4G Module
-
Venoen PC supports it but do not supply any SIM card and LTE module. You should buy them locally and test by yourself. LTE module is necessary, don't forget it.
-
Mini PCIE slot support Wi-Fi module (Half Mini PCIE) by default. If you wanna install LTE module, please leave message that we will move the screw to make a full mini pcie slot for it.
-
When you buy LTE module, please get details like drivers from the supplier.
-
Below HUAWEI LET Module (ME909s-120) is for reference. All orders come without it.
Kind reminder
1. Barebone (No RAM No SSD No WF) package DO NOT include WiFi and Antenna, if you need, please contact us.
2. PC had best to use Samsung, SKhynix, Micron etc original brand accessories, We DO NOT compensate for buyer's own ram and hard drive and DO NOT compensate for man-made damage and faulty.
3. If you need printe OEM logo in your mini pc, please send us the HD picture.
4. Please make sure the shipping address, zip code and tel-number are correct before payment.
5. All SIM-enabled mini PCs need to purchase additional 3G / 4G modules.
About Tax
Due to the tax problem, buyer refuse to receive the goods, buyer need to be fully responsible for the freight back and forth.Thank you for you cooperation.
About Feedback
1. If you are satisfied with our product and service, please leave us positive feedback and 5 star review and images upload.
2. If you are not satisfied, please contact us kindly first. We will try our best to deal with the issue for you or you can exchange or return the item in one week.
About Warranty
1. We provide 30 days replacement and 3 years warranty period, repair for free; but more than two years, charge for parts and shipping charges as appropriate.
2. All returned items must be in its original conditions. Anthropogenic causes as defects are not guaranteed.
